Key Features of the TC-400-TM-RA-D, TNC-Male Right Angle Soldering Connector for LMR-400 Coaxial Cable
The TC-400-TM-RA-D TNC-Male Right Angle Soldering Connector for LMR-400 coaxial cable offers advanced features for RF professionals seeking reliability and compact design:
Solder-Type Center Contact: Ensures a strong, low-resistance connection to the cable’s center conductor for superior signal integrity.
Right-Angle Design: Compact 90-degree configuration ideal for tight spaces and efficient cable routing in dense RF setups.
High-Performance Specifications:
Frequency Range: DC to 6 GHz
Impedance: 50 Ohms
Body Finish: Nickel-plated for corrosion resistance
Pin Finish: Gold-plated for low signal loss and high conductivity
VSWR: Low reflection for consistent signal quality
Durable Construction: Threaded TNC coupling ensures secure mating, with tri-metal plating to withstand vibration, moisture, and extreme temperatures.
The TC-400-TM-RA-D TNC-Male Right Angle Soldering Connector for LMR-400 coaxial cable is a trusted choice for high-frequency applications requiring compact, robust connections.
admin –
Space-saving TNC Male right-angle for LMR-400. Solder-pin/crimp termination ensures robust, weatherproof 6 GHz performance, ideal for managing large cables in confined enclosures and jumpers.
